Engineering & Physical Data MWM-J-2009
Engineering & Physical Data
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT MWM009J MWM015J
OUTDOOR UNIT MLC009C MLC015C
NOMINAL CAPACITY
Btu/h 8400 12000
W 2460 3520
NOMINAL TOTAL INPUT POWER W 925 1176
NOMINAL RUNNING CURRENT A 4.10 5.40
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 2.66 2.99
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 145 / 309 163 / 346
MEDIUM l/s / CFM 125 / 265 138 / 293
LOW l/s / CFM 105 / 223 113 / 240
SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 32 / 29 38 / 34 / 29
UNIT DIMENSION
HEIGHT mm/in 288 / 11.3 288 / 11.3
WIDTH mm/in 800 / 31.5 800 / 31.5
DEPTH mm/in 204 / 8.0 204 / 8.0
PACKING DIMENSION
HEIGHT mm/in 350 / 13.8 350 / 13.8
WIDTH mm/in 874 / 34.4 874 / 34.4
DEPTH mm/in 280 / 11.0 280 / 11.0
UNIT WEIGHT kg/lb 12 / 26.5 12 / 26.5
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 349 / 740 457 / 969
SOUND PRESSURE LEVEL dBA 45 49
UNIT DIMENSION
HEIGHT mm/in 475 / 18.7 540 / 21.3
WIDTH mm/in 600 / 23.6 700 / 27.6
DEPTH mm/in 245 / 9.6 250 / 9.8
PACKING DIMENSION
HEIGHT
mm/in 535 / 21.1 620 / 24.4
WIDTH mm/in 712 / 28.0 810 / 31.9
DEPTH mm/in 320 / 12.6 330 / 13.0
UNIT WEIGHT kg/lb 33 / 72.6 34 / 75.0
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.4 / 1/4 6.4 / 1/4
GAS mm/in 9.5 / 3/8 12.7 / 1/2
REFRIGERANT CHARGE kg/lb 0.65 / 1.43 0.75 / 1.65
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
