MWM-J-2009 Performance Data
Heat Pump (R410A)
Model: M5WM015JR - M5LC015CR
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.593 2.416 3.363 2.186 3.152 1.974 2.940 1.763 2.728 1.551 2.474 1.297
16 3.667 2.252 3.439 2.050 3.219 1.857 2.999 1.665 2.779 1.472 2.515 1.240
24
16 3.667 2.924 3.439 2.723 3.219 2.530 2.999 2.337 2.779 2.144 2.515 1.913
17 3.743 2.761 3.514 2.587 3.286 2.413 3.058 2.239 2.830 2.065 2.556 1.857
18 3.809 2.588 3.576 2.437 3.343 2.285 3.110 2.134 2.877 1.982 2.597 1.801
19 3.875 2.404 3.634 2.213 3.392 2.022 3.151 1.830 2.918 1.791 2.638 1.744
20 3.943 2.236 3.703 2.090 3.463 1.944 3.222 1.797 2.982 1.651 2.693 1.475
28
18 3.809 3.261 3.576 3.110 3.343 2.958 3.110 2.807 2.877 2.655 2.597 2.473
19 3.875 3.077 3.634 2.885 3.392 2.694 3.151 2.503 2.918 2.464 2.638 2.417
20 3.943 2.909 3.703 2.763 3.463 2.616 3.222 2.470 2.892 2.324 2.693 2.148
21 4.011 2.729 3.768 2.566 3.525 2.402 3.283 2.239 3.040 2.075 2.749 1.879
22 4.078 2.549 3.833 2.369 3.588 2.188 3.343 2.007 3.098 1.827 2.804 1.610
23 4.146 2.369 3.898 2.171 3.651 1.974 3.403 1.776 3.156 1.578 2.859 1.341
24 4.213 2.189 3.963 1.974 3.714 1.760 3.464 1.545 3.214 1.330 2.915 1.072
30
20 3.943 3.245 3.703 3.099 3.463 2.953 3.222 2.806 2.982 2.660 2.693 2.484
21 4.011 3.065 3.768 3.902 3.525 3.739 3.283 2.575 3.040 2.412 2.749 2.215
22 4.078 2.885 3.833 2.705 3.588 2.524 3.343 2.344 3.098 2.163 2.804 1.946
23 4.146 2.706 3.989 2.508 3.651 2.310 3.403 2.112 3.156 1.915 2.859 1.678
24 4.213 2.526 3.963 2.311 3.714 2.096 3.464 1.881 3.214 1.666 2.915 1.409
Model: M5WM015JR - M5LC015CR
Heating Mode
ID WB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 2.043 2.043 2.312 2.312 2.402 2.402 3.389 3.389 3.928 3.928 4.197 4.197 4.467 4.467
17 1.989 1.989 2.255 2.255 2.347 2.347 3.385 3.385 3.869 3.869 4.137 4.137 4.406 4.406
19 1.936 1.936 2.197 2.197 2.293 2.293 3.381 3.381 3.810 3.810 4.078 4.078 4.345 4.345
21 1.882 1.882 2.143 2.143 2.238 2.238 3.331 3.331 3.751 3.751 4.018 4.018 4.285 4.285
23 1.829 1.829 2.091 2.091 2.184 2.184 2.236 3.236 3.692 3.692 3.958 3.958 4.224 4.224
25 1.775 1.775 2.038 2.038 2.129 2.129 3.140 3.140 3.633 3.633 3.898 3.898 4.164 4.164
27 1.722 1.722 1.986 1.986 2.074 2.074 3.045 3.045 3.574 3.574 3.839 3.839 4.103 4.103
FROST REGION
