MWM-J-2009 Performance Data
Heat Pump (R22)
Model: MWM009JR - MLC009CR
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.078 1.834 2.841 1.616 2.604 1.398 2.368 1.181 2.131 0.963 1.846 0.702
16 3.080 1.661 2.853 1.472 2.627 1.283 2.401 1.094 2.174 0.905 1.903 0.678
24
16 3.080 2.294 2.853 2.105 2.627 1.916 2.401 1.727 2.174 1.538 1.903 1.311
17 3.081 2.121 2.865 1.961 2.649 1.800 2.434 1.640 2.218 1.479 1.959 1.287
18 3.082 1.949 2.877 1.817 2.672 1.685 2.467 1.553 2.261 1.421 2.015 1.263
19 3.084 1.776 2.889 1.673 2.694 1.569 2.500 1.466 2.305 1.363 2.072 1.239
20 3.085 1.602 2.904 1.521 2.722 1.439 2.541 1.357 2.359 1.275 2.141 1.177
28
18 3.082 2.582 2.877 2.450 2.672 2.318 2.467 2.186 2.261 2.054 2.015 1.896
19 3.084 2.409 2.889 2.306 2.694 2.202 2.500 2.099 2.305 1.996 2.072 1.871
20 3.085 2.235 2.904 2.154 2.722 2.072 2.541 1.990 2.359 1.908 2.141 1.810
21 3.087 2.061 2.920 1.996 2.753 1.931 2.587 1.866 2.420 1.801 2.220 1.723
22 3.089 1.887 2.937 1.839 2.785 1.791 2.633 1.742 2.481 1.694 2.298 1.636
23 3.091 1.713 2.953 1.681 2.816 1.650 2.679 1.618 2.541 1.587 2.377 1.549
24 3.092 1.539 2.970 1.524 2.847 1.509 2.725 1.495 2.602 1.480 2.455 1.462
30
20 3.085 2.552 2.904 2.470 2.722 2.388 2.541 2.306 2.359 2.224 2.141 2.126
21 3.087 2.378 2.920 2.313 2.753 2.248 2.587 2.182 2.420 2.117 2.220 2.039
22 3.089 2.204 2.937 2.155 2.785 2.107 2.633 2.059 2.481 2.010 2.298 1.952
23 3.091 2.030 2.953 1.998 2.816 1.966 2.679 1.935 2.541 1.903 2.377 1.865
24 3.092 1.855 2.970 1.841 2.847 1.826 2.725 1.811 2.602 1.796 2.455 1.778
Model: MWM009JR - MLC009CR
Heating Mode
ID
WB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 1.169 1.169 1.441 1.441 1.532 1.532 2.528 2.528 3.071 3.071 3.343 3.343 3.615 3.615
17 1.145 1.145 1.414 1.414 1.503 1.503 2.523 2.523 2.988 2.988 3.250 3.250 3.512 3.512
19 1.122 1.122 1.386 1.386 1.474 1.474 2.517 2.517 2.904 2.904 3.157 3.157 3.409 3.409
21 1.098 1.098 1.359 1.359 1.445 1.445 2.512 2.512 2.821 2.821 3.064 3.064 3.306 3.306
23 1.090 1.090 1.335 1.335 1.417 1.417 2.386 2.386 2.737 2.737 2.971 2.971 3.204 3.204
25 1.083 1.083 1.312 1.312 1.388 1.388 2.260 2.260 2.654 2.654 2.877 2.877 3.101 3.101
27 1.076 1.076 1.288 1.288 1.359 1.359 2.134 2.134 2.571 2.571 2.784 2.784 2.998 2.998
FROST REGION
