MWM-J-2009 Performance Data
Cooling Only (R410A)
Model: M5WM010J - M5LC010C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.003 1.878 2.793 1.668 2.593 1.468 2.393 1.268 2.193 1.068 1.953 0.828
16 3.060 1.750 2.853 1.560 2.652 1.375 2.450 1.190 2.248 1.005 2.006 0.783
24
16 3.060 2.393 2.853 2.203 2.652 2.018 2.450 1.833 2.248 1.648 2.006 1.426
17 3.125 2.265 2.921 2.095 2.717 1.925 2.513 1.756 2.309 1.586 2.064 1.382
18 3.184 2.132 2.980 1.979 2.776 1.827 2.571 1.674 2.367 1.521 2.122 1.338
19 3.245 1.999 3.046 1.861 2.847 1.724 2.648 1.586 2.435 1.453 2.180 1.293
20 3.303 1.861 3.096 1.711 2.889 1.561 2.681 1.411 2.474 1.261 2.225 1.081
28
18 3.184 2.775 2.980 2.623 2.776 2.470 2.571 2.317 2.367 2.164 2.122 1.981
19 3.245 2.642 3.046 2.505 2.847 2.367 2.648 2.229 2.435 2.096 2.180 1.936
20 3.303 2.504 3.096 2.354 2.889 2.204 2.681 2.054 2.474 1.904 2.225 1.724
21 3.362 2.365 3.152 2.201 2.943 2.037 2.733 1.873 2.523 1.708 2.271 1.512
22 3.421 2.226 3.209 2.048 2.997 1.869 2.784 1.691 2.572 1.513 2.317 1.299
23 3.481 2.087 3.266 1.895 3.051 1.702 2.836 1.510 2.621 1.318 2.363 1.087
24 3.540 1.948 3.322 1.741 3.105 1.535 2.887 1.329 2.670 1.122 2.409 0.875
30
20 3.303 2.825 3.096 2.675 2.889 2.525 2.681 2.375 2.474 2.225 2.225 2.045
21 3.362 2.686 3.152 2.522 2.943 2.358 2.733 2.194 2.523 2.030 2.271 1.833
22 3.421 2.547 3.209 2.369 2.997 2.191 2.784 2.013 2.572 1.835 2.317 1.621
23 3.481 2.408 3.266 2.216 3.051 2.024 2.836 1.831 2.621 1.639 2.363 1.408
24 3.540 2.269 3.322 2.063 3.105 1.857 2.887 1.650 2.670 1.444 2.409 1.196
Model: M5WM015J - M5LC015C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 3.593 2.416 3.363 2.186 3.152 1.974 2.940 1.763 2.728 1.551 2.474 1.297
16 3.667 2.252 3.439 2.050 3.219 1.857 2.999 1.665 2.779 1.472 2.515 1.240
24
16 3.667 2.924 3.439 2.723 3.219 2.530 2.999 2.337 2.779 2.144 2.515 1.913
17 3.743 2.761 3.514 2.587 3.286 2.413 3.058 2.239 2.830 2.065 2.556 1.857
18 3.809 2.588 3.576 2.437 3.343 2.285 3.110 2.134 2.877 1.982 2.597 1.801
19 3.875 2.404 3.634 2.213 3.392 2.022 3.151 1.830 2.918 1.791 2.638 1.744
20 3.943 2.236 3.703 2.090 3.463 1.944 3.222 1.797 2.982 1.651 2.693 1.475
28
18 3.809 3.261 3.576 3.110 3.343 2.958 3.110 2.807 2.877 2.655 2.597 2.473
19 3.875 3.077 3.634 2.885 3.392 2.694 3.151 2.503 2.918 2.464 2.638 2.417
20 3.943 2.909 3.703 2.763 3.463 2.616 3.222 2.407 2.982 2.324 2.693 2.148
21 4.011 2.729 3.768 2.566 3.525 2.402 3.283 2.239 3.040 2.075 2.749 1.879
22 4.078 2.549 3.833 2.369 3.588 2.188 3.343 2.007 3.098 1.827 2.804 1.610
23 4.146 2.369 3.898 2.171 3.651 1.974 3.403 1.776 3.156 1.578 2.859 1.341
24 4.213 2.189 3.963 1.974 3.714 1.760 3.464 1.545 3.214 1.330 2.915 1.072
30
20 3.943 3.245 3.703 3.099 3.463 2.953 3.222 2.806 2.982 2.660 2.693 2.484
21 4.011 3.065 3.768 2.902 3.525 2.739 3.283 2.575 3.040 2.412 2.749 2.215
22 4.078 2.885 3.833 2.705 3.588 2.524 3.343 2.344 3.098 2.163 2.804 1.946
23 4.146 2.706 3.898 2.508 3.651 2.310 3.403 2.112 3.156 1.915 2.859 1.678
24 4.213 2.526 3.963 2.311 3.714 2.096 3.464 1.881 3.214 1.666 2.915 1.409
