McQuay MWM009J

47
Electrical Data MWM-J-2009
Electrical Data - Cooling Only (R410A)
MODEL
INDOOR UNIT M5WM010J M5WM015J
OUTDOOR UNIT M5LC010C M5LC015C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 32 40
RATED RUNNING CURRENT A 0.17 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 52 59
RATED RUNNING CURRENT A 0.23 0.26
MOTOR OUTPUT W 35 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 25.0
RATED INPUT POWER W 741 995
RATED RUNNING CURRENT A 3.30 4.60
LOCKED ROTOR AMP. A 17 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R410A)
MODEL
INDOOR UNIT M5WM010JR M5WM015JR
OUTDOOR UNIT M5LC010CR M5LC015CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 32 40
RATED RUNNING CURRENT A 0.17 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 52 59
RATED RUNNING CURRENT A 0.23 0.26
MOTOR OUTPUT W 35 35
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 25.0
RATED INPUT POWER (COOLING) W 741 995
RATED INPUT POWER (HEATING) W 691 891
RATED RUNNING CURRENT (COOLING) A 3.3 4.6
RATED RUNNING CURRENT (HEATING) A 2.8 4.2
LOCKED ROTOR AMP. A 17 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
