McQuay MWM009J

64
MWM-J-2009 Exploded View and Part List
OUTDOOR UNIT
MODEL: MLC015C, M5LC010/015C
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
No Description Part Number
1 Assy. Base Pan R50014051158
2 Assy. Outdoor Coil
MCL015C R50024100432
M5LC010C R50024099625
M5LC015C R50024099945
3
Valve Bracket R01014051164
4 Compressor
MLC015C R50049027710
M5LC010C R04019030857
M5LC015C R04019030859
5 Assy. Partition R50064055063
6 Assy. Cap Tube
MLC015C R50024100446
M5LC010C R50024099644
M5LC015C R50024099719
7 Bracket, Fan Motor R01014051162Y
8 Fan Motor
MLC015C R03039015323
M5LC010C R03039016104
M5LC015C R03039015323
9 Fan Blade R03019015339
10 Left Panel R01014051166Y
11 Right Panel R01014051167Y
12 Assy. Front Panel R01014051171Y
No Description Part Number
13 Assy. Control Panel
MLC015C R50044086056
M5LC010C R50044086056
M5LC015C R50044086059
14 Assy. Valve Cover R50124051173
15 Assy. Front Grille R50124093630
16 Plastic Handle R12014057948
17 Rubber Grommet
MLC015C R11054000272
M5LC010/015C R11059025038
18 Assy. Flare Valve 2 Ways 1/4”
MLC015C R50059029816
M5LC010/015C R50059019453
19 Assy. Flare Valve 3 Ways 3/8”
M5LC010C R50059019454
Assy. Flare Valve 3 Ways 1/2”
MLC015C R50059029814
M5LC015C R50059019452
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor
MLC015C R04029026775
M5LC010C R04029026775
M5LC015C R04029026774
