66
MWM-J-2009 Exploded View and Part List
OUTDOOR UNIT
MODEL: MLC009CR
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
No Description Part Number
1 Assy. Base Pan R50014057372
2 Assy. Outdoor Coil R50024100431
3
Valve Bracket
R01014051164
4 Compressor R04019031528
5 Assy. Partition R50064084355
6 Assy. 4 Way Valve R05019004157
7 Assy. Cap Tube R50024102031
8 Bracket, Fan Motor R01014052516
9 Fan Motor R03039028206
10 Fan Blade R03019020744
11 Left Panel R01014052510Y
12 Right Panel R01014084434Y
13 Assy. Front Panel R01014052512
No Description Part Number
14 Assy. Control Panel R50044093283
15 Assy. Valve Cover R50124055172
16 Assy. Front Grille R50124093629
17 Plastic Handle R12014057948
18 Rubber Grommet R11054069501
19 Assy. Flare Valve 2
Ways 1/4”
R50059029814
20 Assy. Flare Valve 3
Ways 3/8”
R50059029815
21 Sensor, Outdoor Defrost R50134039416
Parts Not in Diagram
22 Capacitor, Fan Motor R04029026755
Capacitor, Compressor R04029026775
14_Exploded view.indd 6614_Exploded view.indd 66 3/6/2009 5:01:40 PM3/6/2009 5:01:40 PM
