MWM-J-2009 Exploded View and Part List
OUTDOOR UNIT
MODEL: MLC015CR, M5LC010/015CR
No Description Part Number
1 Assy. Base Pan R50014051158
2 Assy. Outdoor Coil
MLC015CR R50024100642
M5LC010CR R50024099516
M5LC015CR R50024099608
3
Valve Bracket R01014051164
4 Compressor
MLC015CR R04019027709
M5LC010CR R04019030857
M5LC015CR R04019030859
5 Assy. Partition R50064055063
6 Assy. 4 Way Valve
MLC015CR R05019004158
M5LC010/015CR R05019010936
7 Assy. Cap Tube
MLC015CR R50024102451
M5LC010CR R50024099815
M5LC015CR R50024099643
8 Bracket, Fan Motor R01014051162Y
9 Fan Motor
MLC015CR R03039015323
M5LC010CR R03039016104
M5LC015CR R03039015323
10 Fan Blade R03019015339
11 Left Panel R01014051166Y
12 Right Panel R01014051167Y
No Description Part Number
13 Assy. Front Panel R01014051171Y
14 Assy. Control Panel
MLC015CR R50044086062
M5LC010CR R50044086062
M5LC015CR R50044086065
15 Assy. Valve Cover R50124051173
16 Assy. Front Grille R50124093630
17 Plastic Handle R12014057948
18 Rubber Grommet
MLC015CR R11054000272
M5LC010/015CR R11059025038
19 Assy. Flare Valve 2 Ways 1/4”
MLC015CR R50059029814
M5LC010/015CR R50059019453
20 Assy. Flare Valve 3 Ways 3/8”
M5LC010CR R50059019454
Assy. Flare Valve 3 Ways 1/2”
MLC015CR R50059029816
M5LC015CR R50059019452
21 Sensor, Outdoor Defrost R50134039416
Parts Not in Diagram
Capacitor, Fan Motor R04029026755
Capacitor, Compressor
MLC015C R04029026775
M5LC010C R04029026775
M5LC015C R04029026774
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
