IM708 13
Unit Weights
Table 6. Unit and Component Weight in lbs.
Unit Weights
Unit Size
018 023 028 035 040 045 055 065 070 080 095 105
Basic Configuration
SWP basic unit
a
2226 2313 2318 2638 2643 3110 3279 3406 3734 4021 4246 4673
Filters
4" 30% or 65% efficiency 38 38 38 55 55 66 66 79 87 96 104 112
Evaporator Coil
6 Row, 12 fpi 250 294 321 417 468 506 577 642 693 755 819 926
4 Row, 12 fpi 206238257333368395------
Water Economizer Coil
b
c
4 Row, 12 fpi 306 338 357 458 493 520 598 648 678 723 820 927
Water weight 51 66 75 94 111 119 150 168 187 203 218 281
Hot Water Coil
d
c
1 Row, 12 fpi 71 97 114 130 158 160 170 200 328 337 345 371
Water weight 16 20 23 28 32 37 41 49 55 59 62 62
Electric Heat
34 KW 2020202020-------
68 KW -----40404040404040
Supply Fan Motors
3 HP ODP 71------ ----
5 HP ODP 82------ ----
7.5 HP ODP 124124----- ----
10 HP ODP 144 144 144 144 - - - - - - -
15 HP ODP - 185 185 185 185 185 - - - - -
20 HP ODP - - 214 214 214 214 214 214 214 - - -
25 HP ODP - - - - 266 266 266 266 266 266 - -
30 HP ODP - - - - - 310 310 310 310 310 310 -
40 HP ODP ------404404404404404404
50 HP ODP ------- -452452452
60 HP ODP ------- --620620
75 HP ODP ------- ---836
3 HP TEFC 72------ ----
5 HP TEFC 85------ ----
7.5 HP TEFC 140140----- ----
10 HP TEFC 170 170 170 170 - - - - - - -
15 HP TEFC - 235 235 235 235 235 - - - - -
20 HP TEFC - - 300 300 300 300 300 300 300 - - -
25 HP TEFC - - - - 330 330 330 330 330 330 - -
30 HP TEFC - - - - - 390 390 390 390 390 390 -
40 HP TEFC ------510510510510510510
50 HP TEFC ------- -570570570
60 HP TEFC ------- --850850
75 HP TEFC ------- ---900
Compressor/Condenser Assembly
Water Weight
(2)6HP 26 368------ ----
(3)6HP 35 538538----- ----
(4)6HP 43 699 699 699 699 - - - - - - -
(3)6HP, (1)10HP 57 - 843 843 843 843 - - - - - -
(2)6HP, (2)10HP 66 - - 974 974 974 - - - - - -
(1)6HP, (3)10HP 74 - - - 1115 1115 - - - - - -
(4)10HP 95 - - - 1263 1263 1263 1263 1263 - - - -
(2)10HP, (2)13HP 106 - - - - - 1404 1404 1404 - - - -
(4)13HP 118 - - - - - 1549 1549 1549 1549 - - -
(2)13HP, (2)15HP 129 - - - - - 1709 1709 1709 1709 1709 1709 -
(4)15HP 141 - - - - - 1867 1867 1867 1867 1867 1867 -
(2)15HP, (2)20HP 152 -------198219821982 1982 -
(4)20HP 190 ------- -2096 2096 -
(6)13HP 167 ------- --22652265
(3)13HP, (3)15HP 178 ------- --24792479
(6)15HP 188 ------- --26932693
(3)15HP, (3)20HP 209 ------- --29142914
(6)20HP 229 ------- --31353135
Discharge Plenum
Factory Installed, 29” 636 636 636 711 711 862 862 862 922 1003 1064 1064
a. Base Weight includes supply fan without motor.
b. Water economizer weight includes valves and piping.
c. The values in this table do not include water weight.
d. Hot water coil weight includes valve and piping.
To Next Page
