VIEW CIR STATUS (2)
Hours = XXXXX
Starts = XXXXX
KW Hours= XXXXXXX
A KW hours counter has been added to the Circuit control Circuit Status Screen. The KW
Hours field will display up to 9,999,999 kW-Hours.
VIEW CIR STATUS (3)
Current (amps)
L1 L2 L3 Avg
XXX XXX XXX XXX
VIEW CIR STATUS (4)
Voltage
L1-2 L2-3 L3-1 Avg
XXX XXX XXX XXX
VIEW CIR STATUS (5)
PF= 0.XX %RLA=XXX.X
KW= XXX
KVA= XXX
VIEW CIR STATUS (6)
Digital Outputs
1 2 3 4 5 6 7 8 9 10
X X X X X X X X X X
Status will be “0” for OFF and “!” for ON.
VIEW CIR STATUS (7)
Digital Outputs
11 12 13
X X X
VIEW CIR STATUS (8)
Analog Outputs
(volts X 100)
1=XXXX 3=XXXX
VIEW CIR STATUS (9)
Digital Inputs
1 3 4 5 6 9
X X X X X X
View Refrigerant
VIEW REFRIGERANT (1)
Evap Press=XXX.X psi
Cond Press=XXX.X psi
VIEW REFRIGERANT (2)
