MCS Master XL 6 - Unpacking; Fuel; Operating Principle; Operation

►►2. UNPACKING
See Fig. 1
►2.1. Remove all the heater wrapping and
packaging materials then dispose of them
as per the applicable local regulations.
►2.2. Remove all the components from the
box.
►2.3. Check for any damage during transport.
If the heater appears damaged in any way,
please inform your vendor promptly.
►►3. FUEL
!
WARNING: The heater only runs on
DIESEL or KEROSENE fuel.
To avoid re or explosion, use only diesel
or kerosene fuel. Do not use gasoline,
naphtha, paint thinners, alcohol or any other
combustible liquids.
For low-temperature operation, use antifreeze
supplements.
►►4. OPERATING PRINCIPLE
See Fig. 2
Airow is necessary to ensure proper
combustion, it is supplied by the internal
burner fan. The air enters the burner funnel
and gets mixed with a high-pressure fuel jet.
The fuel ow is secured by an electrical pump,
which sucks the fuel away from the tank and
moves it to the nozzle under high pressure.
►►5. OPERATION
!
WARNING: Read the section
“SAFETY CONSIDERATIONS” carefully
before turning the heater on.
►►5.1. RUNNING THE HEATER:
►5.1.1. Observe all safety instructions at all
times.
►5.1.2. Check if fuel is present in the tank.
►5.1.3. Close the fuel tank ller plug.
►5.1.4. Plug the feeder cable into the socket
(CHECK THE VOLTAGE IN ”TECHNICAL
DATA SHEET”).
►5.1.5. Turn the “ON/OFF” switch “ON” (|)
(C Fig. 3). The heater should be online in
a few seconds. If it is not, please refer to
the section “PROBLEM IDENTIFICATION”
(Paragraph 10).
►5.1.6. Check the position of the thermostat
(C Fig. 3).
NOTE: IN THE EVENT OF HEATER BEING
TURNED OFF DUE TO RUNNING OUT OF
FUEL, TURN THE HEATER OFF, REFUEL
AND TURN IT BACK ON (SEE PARA. 5.1.).
►►5.2. TURNING THE HEATER OFF:
!
WARNING: DO NOT CUT THE POWER
OR DISCONNECT THE FEEDER CABLE
BEFORE THE HEATER COOLS DOWN
COMPLETELY (ab. 5 minutes).
►5.2.1. Turn the “ON/OFF” switch “OFF” (0)
(A Fig. 3).
►►6. CLEANING THE FUEL
FILTER
See Fig. 4
DEPENDING ON THE QUALITY OF FUEL
USED, IT MAY BE NECESSARY TO CLEAN
THE FUEL FILTER.
►6.1. Remove the plug on the fuel tank (A
Fig. 4).
►6.2. Remove the lter from the tank.
►6.3. Unscrew the cap (B Fig. 4).
►6.4. Remove the lter (C Fig. 4).
►6.6. Clean the lter using clean fuel, do not
damage the lter.
►6.6. Replace the lter inside the tank.
►►7. MAINTENANCE AND
TRANSPORTATION
TO ENSURE THE BEST MAINTENANCE
AND/OR TRANSPORTATION PROCEDURE,
PLEASE OBSERVE THE FOLLOWING
PROCEDURE:
►7.1. Empty the fuel tank.
►7.2. If remainders are still present, pour in
clean fuel and empty it again.
►7.3. Close the tank ller plug, dispose of the
fuel as per the applicable regulations.
►7.4. To ensure proper heater maintenance,
keep it leveled to prevent fuel leaks, keep
it in a dry place and protect from getting
damaged.
