23
Control Panel
Control panel with functions indicated.
1. Water Level Indicator
2. Main Isolation Switch
3. Automatic Circuit Breaker
4. LED Battery Voltage Indicator
5. LED Amp Meter
6. Auxiliary 12v lighter socket
7. Water pump switch
8. Fridge Socket Power Switch
9. Internal Camper Lights Main Switch
10. 12V DC Sockets Main Switch
11. Spare switch for additional 12v
12. Resettable Circuit Breakers for each
Switch
*Volt Meter will indicate battery voltage when idle or charge voltage when charging
* Amp meter will show current being used not charge current
Gas & Water Systems
Hot Water System
If your camper came with a Country Comfort portable hot water system, please refer to the owner manual or their
website for more information.
https://countrycomfortlpggas.com.au/
Water Pumps
The pump when switched on is activated by the release of pressure at the tap and will pump water continuously until
the tap is turned off and pressure restored. Should the pumps activate while the taps is turned off this could indicate a
leak and require investigation and rectification.
Connecting the Gas
Your camper is fitted with plumbed gas with the regulator and gas bottle placement at the front of the trailer. Always
ensure gas bottles are serviceable and within the 10 year service life. This information is stamped on the bottle base.
Once you connect your gas bottle you can connect the kitchen gas hose to the bayonet connection provided. Once the
bayonet is
secure, ensure all controls on the stove are in the “Off” position and then turn on the gas bottle valve. If your kitchen
stove is fitted with electric ignition, plug the connector into the 12v socket beside the kitchen and turn on the required
burner whilst pressing the ignition button. When the burner ignites hold the button down for 5 seconds then release.
NOTE: It will take up to a minute or so for the gas to purge the line and flow through the burners.
