24 MDS TransNET I&O Guide MDS 05-2708A01, Rev. D
Table 8. Network-Wide Diagnostics
Command Description
DLINK [xxxxx/ON/OFF]
Details, page 32
Controls operation of diagnostic link function.
DTYPE [NODE/ROOT]
Details, page 33
Set radio’s operational characteristics for
network-wide diagnostics
Table 9. Operational Configuration—Set/Program
Command Description
ADDR [1–65000]
Details, page 29
Program network address
AMASK [0000 0000–FFFF FFFF]
Details, page 29
Alarm response
Default: FFFF FFFF
ASENSE [HI/LO]
Details, page 29
Sense of the alarm output on Pin 6 of the
DATA interface connector in the EIA-232
mode. Default: Alarm present = HI
BAND [A, B, C]
Details Page 30
Selects one of three operating bands.
(2.4 GHz Model Only)
BAUD [xxxxx abc]
Details, page 29
Data communication parameters
CODE [NONE, 1…255]
Details, page 31
Select the security/encryption setting in the
radio
CSADDR [1–65000, NONE]
Details, page 31
Used on a single Master/Remote network to
support TDD-style simulated full-duplex.
CTS [0–255]
Details, page 31
CTS delay in milliseconds
(A value of 0 returns CTS immediately)
CTSHOLD [0–60000]
Details, page 32
“Hold time” that CTS is present following last
character from DATA port.
DEVICE [DCE, CTS KEY]
Details, page 32
Device behavior:
DCE (normal) or CTS Key
MODE [M, R, X]
Details, page 36
Operating mode:
M = Master, R = Remote, X = Extension
MRSSI [NONE, –40...–90]
Details, page 37
Minimum RSSI level required to preserve syn-
chronization with a Master radio for Remotes
in mobile service.
OT [ON, OFF]
Details, page 37
Enables a 1-second delay on delivery of RXD
serial data.
