On the applicator and cartridge you will nd
1. Light output window: The light energy ashes out through the treatment window.
2. RF skin contact bars: The 2 RF bars must be in complete contact with the skin for the
light pulses to ash.
3. Cartridge: The cartridge comes attached to the applicator and is preloaded with
light pulses. You will need to replace the cartridge when the Empty indicator light on
the base unit is red.
4. Cartridge activation button: Press on this button to turn on the elōs cartridge.
You will hear the fan turn on, and the activation indicator will light up.
5. Cooling inlet: hot air is forced out of the cooling inlet in order to keep the hand
piece cool while in use.
6. Protective cap.
2
3
5
1
6
4
