Meade ETX-80 - Page 19

19
ETX 90/125 KEY FEATURES
Figure 13: ETX 90/125 Left Side
Figure 15: ETX 90/125 Top of Base
Figure 14: ETX 90/125 Dust Cap
Figure 18: ETX 90 Control Panel
Figure 17: ETX 90/125 Red Dot
Figure 16: ETX 90/125 Bubble Level
13
18
15
14
16
20
19
5a
17
5b
13. Vertical setting
circle
14. 90°ÀLSPLUURU
15. Front lens
16. OTA mounting
thumbscrews(2)
(ETX 90 ONLY)
17. Bubble level/com-
pass
18. Horizontal lock
knob
19. Battery compart-
ment
20. Horizontal setting
circle
5a. On/Off Switch
E5HGGRW¿QGHU
adjustment knobs
12a. Handbox (HBX) port
12b. Power LED
12c. On/Off switch
12d. Auxiliary (AUX) port
12e. Power port
(12v compatible)
12d
12c
12b
12a
12e
7
(ETX90 only)
