NAVIGATING THROUGH THE MODES
The main unit has five (5) different modes (windows) displaying separate data: Weather Forecast, Clock & Alarm, Temperature
and Humidity, Rain, and Wind. When a specific mode is selected the corresponding icon begins flashing.
Press UP button to cycle through the modes clockwise or DOWN ? button for counter-clockwise.
Pressure and Weather Forecast Window
Displays:
• Current pressure and history bar-chart
• Weather forecast
• Moon phase
A. UP ?
- Mode Selection: selects the next available mode counter-clockwise
- When programming: increases parameters
B. DOWN ?
C. SET
D. CHANNEL
- Mode Selection: selects the next available mode clockwise
- When programming: decreases parameters
- Rotates display for current mode
- Press and hold: to enter the programming mode
- Locks in: set parameters
- Manually selects the channel # for receiving temperature and humidity sensor data
- Enables the temperature and humidity channel auto-scan mode
E. MEMORY
- Records: moon phase, temperature, humidity, rainfall and wind records. Then stores
in memory
- Moon phase: Determined by the day of month interval
- Sets and stores pressure & altitude units in Memory
F. HISTORY
G. ALARM/CHART
H. BATTERY
COMPARTMENT
- Displays sea-level pressure history
- Displays alarm times and programmed alerts for temperature, rainfall and wind.
- Press and hold, to enter the alarm/alert programming mode
- Press and hold in pressure and forecast mode, to view different bar charts
- Requires four (4) AA size batteries
I. TABEL STAND
J. SNOOZE
K. AC/ DC
ADAPTOR INPUT
- Places the main unit on the table or other horizontal surface
- Activates Snooze delay for alarms (programmable 1 to 15 minutes)
- Connects main unit to the power outlet through the AC to 7.5V DC adapter provided
