SPECIFICATIONS
OVERALL DIMENSIONS
2
www. mechmaxx.com
SPECIFICATIONS
Engine
Model
Ducar
SG380
Engine Type Single cylinder, 4 stroke, air-cooled, OHV
Engine Displacement
420cc
Horsepower
15hp
Cutting Depth
Cutting Height
Start
10 in below ground
15 in above ground
E-start
Max. Stump Dia. 32 in
Rotary Chassis Yes
Max. Rotation Angle 65 degrees
Max. Rotating Distance 31.5 in
Belt 2x V-belts
Coupler
2 in ball
Cutting Wheel Dia. 14 in
Tire 145/70-6 tubeless tyre
Tip Holder Material 42CrMo
Gross Weight 353 lbs
Packing Size (L*W*H) 45*30*29.5 in
Warranty 1-Year
1154mm
45.4”
2510mm
98.9”
815mm
32”
