MechMaxx TCR1500 - Specifications; Overall Dimensions

SPECIFICATIONS
OVERALL DIMENSIONS
2
www. mechmaxx.com
SPECIFICATIONS
Engine
Model
Ducar
TCR1500
Engine Type Single cylinder, 4 stroke, air-cooled, OHV
Engine Displacement
420cc
Horsepower
15hp
Belts Material
Belt
Start
Kevlar
2 x V-belts
E-Start
Clutch Centrifugal clutch
Carbide Tip 27 x carbide alloy high-pressure teeth
Scraper 9 pcs
Chain Length 81.5 in
Chain Speed 574 ft/min
Max. Trench Depth 24 in
Max. Trench Width 4 in
Wheelbase 29 in
Tire 15*6-6 tubeless tire
Gross Weight 450 lbs
Packing Size (L*W*H)
Warranty
46*31*34 in
1-Year
1234mm
48.5”
2143mm
84.3”
905mm
35.6”
