SONNET 7
Mind the correct
orientation of the
coil cable socket.
Plug the coil cable into
the control unit.
2
Insert the batteries with the
positive
poles facing out.
Make sure the battery pack
cover lock is in the unlocked
position. Slide the battery
pack cover over the battery
pack frame. Your SONNET is
now switched on.
3
Battery Pack
Cover Lock
Locked
Unlocked
