Fitting Kit

SEC-B

OUTLET PORT

Note: If this port is blanked off,

use port on base of valve.

WALL MOUNTING STRAP

NOTES:

Solenoid coil of the valve should never be mounted below the horizontal.

Pressure sender unit should never be mounted upside down (to protect from water ingress)

Approx 400mm length

INLET PORT & OUTLET PORT

Note: These ports could be

side by side

Mounting details - Fitting kit

PRESSURE SENDER UNIT

INLET PORT

Fitting kit - Contents
