1-3
Getting Started
- 1 parallel port
- Audio * 3 in vertical for 6 channels Line-out, 2 in vertical for MIC & Line-
in
- 1 standard 1394 connector
- 1 mini 1394 connector
- 5 USB ports (3 front + 2 rear)
- 1 RJ-45 Lan Jack (optional)
- PS2 KB/Mouse
Onboard IEEE1394
h Integrated in SiS 963 SB
h AGREE FW803
Audio
h S/W RealTek ALC650 6-channel audio codec with SPDIF in/out
LAN
h Realtek RTL8201BL
BIOS
h The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
h The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
h M-ATX Form Factor: 24.4 cm x 23.0 cm
Mounting
h 6 mounting holes.
Others
h Suspend to RAM/Disk (S3/S4)
h PC2001 compliant
h Chassis Intrusion Detection
