GB
36
Application
8. With one of the controls or , set the desired pulse width (50 to 300 S).
9. Briefl y press the button “Set”. The display “ramp.” (ramp time) will illumi-
nate and the ramp time will blink on the display .
10. Set the desired ramp time (1 to 10 sec.) with one of the controls or .
11. Briefl y press the button “Set”. The display “con.” (continuous time) will
illuminate and the continuous time will blink on the display .
12. Set the desired continuous time (1 to 20 sec.) with one of the controls or .
13 . B r i e fl y press the button “Set”. The display “rel.” (relax time) will illuminate
and the relax time will blink on the display .
14. With one of the controls or , set the desired relax time (1 to 20 sec.).
15 . B r i e fl y press the button “Set”.
This program has now been saved and can be used like a preset program (see
page 33 and 34).
In order to reset the self-defi ned programs to the factory default, hold the but-
ton “
” with the device on for approximately 5 seconds until a long signal is
audible.
Factory settings for the programs:
TENS
Program Duration Frequency Pulse width
U-01 30 min. 50 Hz 200 s
U-02 30 min. 1.0 Hz 100 s
EMS
Program Duration Fre-
quency
Pulse
width
Ramp/
drop
Continu-
ous time
Relax
U-01 30 min. 80 Hz 150 s 1 sec. 8 sec. 5 sec.
Delete defi ned
programs
