17
GENERAL USE INSTRUCTIONS
To Swing-away / Remove the Legrest assembly:
1. Fold the footplate up to the vertical position.
2. Release the legrest lock by pushing on the legrest lever.
3. Swing the legrest outward and to the side.
4. To remove the legrest, lift up on the assembly to remove the legrest off the hinge
pins.
To adjust the footplate assembly:
1. Loosen the plunger by pulling it out so it is perpendicular with the leg rest
2. Engage the two push buttons by pushing them in and adjust the footplate
assembly to your desired height. Release the push buttons and ensure they are
protruded and locked in place.
3. Lock the plunger by pushing it in the down position.
Push button
Plunger
1
2 3
