16
GENERAL USE INSTRUCTIONS
For models: MDS808210ARE, MDS808210ABE
To use Locking Hand Grip Brakes
Handle grip wheel lock in open /
unlocked position.
Squeeze brake to hold transport
chair in stopped position.
Handle grip wheel lock in closed /
locked position.
To Lock, push down on the handle
until wheel lock engages
To Release, squeeze handle.
Installing / Removing the Swing-away Leg rest / Footrest Riggings
To Install the Riggings:
1. Hold the leg rest rigging to the side of the transport chair.
2. Slide one side of the leg rigging onto the hinge pins, swing the leg rigging out until
it clamp locks into place. Repeat this step for the other leg rigging.
Hinge pins
