Medline MDS86845B User Manual


MDS86845 (GPI171)
Revised (A): 09/13/2013
A. Handgrips
B. Adjustable
Handlebar
C. Handlebar Height
Adjust Lock
D. Back Rest
E. Padded Seat
F. Handlebar Folding
Mechanism
G. Adjustment Knob
H. Brake Handle/Lock
I. Brake Cable
J. Triangular
Knob Screw
K. 8" (203 mm)
Front Wheels
L. 8" (203 mm)
Rear Wheels
M. Brake Shoe
Rollator Components

2 Front Wheels
2 Handlebars
2 Rear Wheels




Assembly Instructions
Assembled Rollator
Figure 1
Assembled Rollator
A
B
C
D
I
E
J
G
F
H
FRONT
BACK
M
I
L
K
