DC 00573 TSA 2 Quick Set Up and Installation Overview Rev.1 Date of issue: 10.06. 2019 Page 2 of 9
Patient response unit connection
1. The Response Unit plug is colored yellow. It connects to the yellow port (marked Response Unit) in the system in
the upper quadrant.
2. Please make sure the arrows on the plug are facing up.
3. Make sure you hear a Click when inserting the plug.
4. When not in use, place the Response Unit in the middle holder position.
1 - Thermode Plug
2 – Coolant connectors
Figure 2: Thermode connection
Figure 3: Patient response unit connection
