Mega Lite Mega Air DMX - Technical Specifications; Part Numbers; Electronic Specifications; Mechanical Specifications

4
9505– Mega Air DMX Transmitter
9506– Mega Air DMX Receiver
Electronic Specifications
Fixture Packaging
Size: 4.85” x 4.10” x 4.35”
Weight: 1lb
Size: 7.5” x 6.5” x ”
Weight: 1.5lb
Mechanical Specifications
Part Numbers
4.10”
4.35”
4.85”
Technical Information
Radio Frequency Used: 2.40-252G Automatic Select
126 Channels using frequency
Hopping technology—AFHSS
Frequency Agile: Adaptive
Universes: Up to 16 selectable
Broadcast Power: 20dBm max
Communication distance: Up to 200Meters (Outdoor prime
operating environment)
Power Supply: Electronic 100v220v AC 9V DC
Protocol: DMX 512
Display: Power indicator & Connection status
Compliant : This device complies with part 15 of the FCC rules
Fastening System: Mounting Holes
Power Connection: Dc9V Connection
Signal Connection: XLR 3 & 5 pin in
