Mega Lite Nova-Lite UV200 - Main Control Menu

To Next Page

To Previous Page

Display Menu

DMX Address

Press Set Up to select the DMX start channel use the up/down keys, Press Set Up to confirm the setting

DMX Mode

This function allows you to select the mode in witch you want to control the fixture. Press Enter use the up/down keys to

select desired DMX mode settings. Press Enter to confirm the settings.

1 CH

2 CH

3 CH

Dimmer

Dimmer, Strobe

Dimmer, Strobe, Dim Speed

Color Dimmer

This function allows you to dim up or down the LED’s . Press Enter use the up/down keys to select desired color to ad-

just settings.

Mode Enter Up

Down

CONTROL BOARD

MegaLite

NovaUV200

DMX

Address

Channel Mode

Dimmer

Val:255

Use the up/down keys to select desired intensity. Press Enter to confirm.

(note; Last set intensity will return when in Dimmer mode.)
