40
www.mega-motion.com Endeavor X
NYLON LOCK NUT REPLACEMENT
Any nylon insert lock nut removed during the periodic maintenance, assembly, or disassembly of the
scooter must be replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause
damage to the nylon insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available
at local hardware stores or through your authorized Mega Motion Provider.
WARNING! Failure to ensure that the axle key is properly installed into the axle
slot when mounting the wheel can result in electronic brake failure and/or
product damage.
10. Reinstall the drive wheel nut and washer onto the axle and tighten.
WARNING! Make sure both the nut and washer are reinstalled and tightened properly.
11. Inflate pneumatic tires to the psi/bar/kPa air pressure rating indicated on each tire.
12. Remove the blocks from beneath the scooter.
CONSOLE, CHARGER, AND ELECTRONIC CONTROLLER MODULE
Keep these areas away from moisture.
Before operating your scooter, allow any of these areas to dry thoroughly if they have been exposed to
moisture.
ABS PLASTIC SHROUDS
The front tiller shroud, front shroud, and the rear shroud are formed from durable ABS plastic and are
coated with an advanced formula urethane paint.
A light application of car wax will help the shrouds retain their high gloss.
FUSE REPLACEMENT
To replace a fuse:
1. Remove the fuse by pulling it straight out of its slot.
2. Examine the fuse to be sure it is blown. See figures 28 and 29.
3. Insert a new fuse of the proper rating.
WARNING! The replacement fuse must exactly match the rating of the fuse being
replaced. Failure to use properly rated fuses may cause damage to the electrical system.
IX. CARE AND MAINTENANCE
Figure 28. Working Fuse Figure 29. Blown Fuse (Replace)
