Mega BEAM 200 - Page 11

11
CH4
(Gobo)
0~6 White
7~13 Gobo 1
14~20 Gobo 2
21~27 Gobo 3
28~34
Gobo 4
35~41
Gobo 5
42~48
Gobo 6
49~55
Gobo 7
56~62
Gobo 8
63~69 Gobo 9
70~76 Gobo 10
77~83 Gobo 11
84~90 Gobo 12
91~97 Gobo 13
98~104 Gobo 14
105~111
Gobo 15
112~118
Gobo 16
119~127
Gobo 17
128~191
Gobo veering (slow~Fast)
192~255 Gobo effect with inversion
(slow~Fast)
CH5
(Prism)
0~31
No function
32~255
Prism
CH6
(Prism Rotation)
0~127
No function
128~191 reversion (Fast~slow)
192~255 veering (slow~Fast)
CH7
(Gobo shake)
0 No function
1~191 Gobo shake(Slow~Fast)
192~255 No function
CH8 0~255 Frost
CH9
0~255
Focus
CH10
0~255
Pan
CH11
0~255
Pan fine
CH12
0~255
Tilt
CH13 0~255 Tilt fine
CH14 0~255 Pan/ Tilt speed (Fast~slow)
CH15
0~254 No function
255 Reset
CH16
(The lamp control)
0~100 No function
100~105 Delay closing
106~199
No function
200~205
Delay open
206~255
