1) Address settings DMX address settings:001-255
2) Control mode
3) Option mode
◆ X-axis inversion Off --X-axis forward work(default setting)
ON--X-axis inverse work
◆ Y-axis inversion Off --Y-axis forward work(default setting)
On Up-Y-axis inverse work
◆Opt coupler check Off-- On X/Y axis opt coupler check
4) Display mode Display parameters settings
◆ Language English/Chinese
◆Screen lightness 1-32
◆Screen poorlight Constant open / Dim / Off
◆LOGO display LOGO display On/Off
◆Screen rotate Off--normal display--(default setting)
On--180° rotating display
5) Test mode Light work settings
◆Auto operation Auto operation
◆Sound mode Sound mode
6) Man control mode Light work settings
◆Press “Menu” , and choose Man control by “UP&DOWN”，it will be show CH1 to CH16, to
confirm by press “ENTER” button.
7) Lamp settings Lamp work settings
◆Lamp switch On/Off(Lamp switch need On)
◆Lamp starting state On/Off((Lamp starting state need On)
8) Factory settings Initialized light for parameters
9) Rest settings Motor rest
10) Version Ver4.1
