Megger DET3TA - Page 7

DET3TC DET3TD
7
Test lead connections
(at rear)
Resistance
measurement settings
(2P, 3P and clamp)
Selector switch
Voltage and current
measurement settings
Test button
Digital LCD display
Digital LCD display
Warning - refer to
User manual
Battery charge
indicator
Measuring range
Measuring range
Ruptured fuse
indicator
Over/under range
indicator
Potential probe
resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Clamp current indicator
(OK or low)
Ground noise voltage
indicator (OK high)
Test lead connections (at rear of instrument)
Test lead connections (at rear of instrument)
Warning - refer to
User manual
Over/under range
indicator
Ruptured fuse
indicator
Potential probe
resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Ground noise voltage
indicator (OK high)
Battery charge
indicator
Test lead connections
(at rear)
Resistance
measurement settings
(2P and 3P)
Selector switch
Voltage measurement
settings
Test button
