Megger DET4TCR2 User Manual

15
DET4TD2
LCD display
Test button
Voltage measurement
settings
Test lead connections
(at rear)
Resistance measurement settings
(2P, 3P and 4P)
Selector switch
Test lead connections (at rear of instrument)
Output voltage
indicator
Warning – refer to
user manual
Ruptured fuse
indicator
Battery charge
indicator
Measuring range
Ground noise voltage
indicator (OK high)
Current probe
resistance (OK or
high)
Potential probe
resistance indicator
(OK or high)
25 V/50 V output
voltage select
button
Over/under
range
indicator
