Megger DET4TCR2 User Manual

16
DET4TR2
Test lead connections (at rear of instrument)
Test button
LCD display
Test lead connection
(at rear)
Resistance measurement settings
(2P, 3P and 4P)
Selector switch
Voltage measurement
settings
25 V/50 V output
voltage select button
Output voltage
indicator
Battery charge
indicator
Warning – refer to
user manual
Ruptured fuse
indicator
Potential probe
Resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Ground noise voltage
indicator (OK high)
Measuring range
Over/
under
range
indicator
