14
DET3TD
LCD display
Voltage measurement settings
Test lead connections (at
rear)
Resistance measurement
settings (2P and 3P)
Selector switch
Test lead connections (at rear of instrument)
Test button
25 V/50 V output voltage select button
Output voltage
indicator
Battery charge
indicator
Warning – refer to
user manual
Ruptured fuse
indicator
Potential probe
Resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Ground noise voltage
indicator (OK high)
Measuring range
Over/
under
range
indicator
