16
DET4TR2
Test lead connections (at rear of instrument)
Test button
LCD display
Test lead connection
(at rear)
Resistance measurement settings
(2P, 3P and 4P)
Selector switch
Voltage measurement
settings
25 V/50 V output
voltage select button
Output voltage
indicator
Battery charge
indicator
Warning – refer to
user manual
Ruptured fuse
indicator
Potential probe
Resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Ground noise voltage
indicator (OK high)
Measuring range
Over/
under
range
indicator
