17. Specification
Input voltage Up to 250 V (single phase system) / up to 430 V (three phase
system),
Input Frequency 50/60 Hz,
Type 1 Charging Plug Type 1 AC charging mode 3, suitable to IEC 62196-2 type 1 or
SAE J1772 with vehicle connector (Type 1, 5P single-phase)
Type 2 Charging Plug Type 2 AC charging mode 3, suitable to IEC 62196-2 type 2
socket outlet or fixed cable with vehicle connector (Type 2, 7P
three-phase)
PE Pre-Test Yes - Button
PP Simulation NC, 13 A, 20 A, 32 A, 63 A
CP States A, B, C, D
CP Error “E” Yes
PE Error (Earth fault) Yes
Measuring Ports Max. 250/430 V AC, CAT II 250 V, max. 10 A
L1, L2, L3, N and PE
Mains socket Max. 250 V AC, CAT II 250 V, max. 10 A,
Note: Do not load mains socket simultaneously with measuring ports!
CP Signal output Ports Approx. +/-12 V, CAT 0 (under normal condition)
Measurement category CAT II 250 V
Altitude above sea level. 2000 m max.
Dimensions (W × H × L) 109 mm x 227 mm x 63 mm (without connection cable and
test cable)
Weight Approx: 780 g
CE directive Low Voltage Directive LVD 2014/35/EU
Safety IEC/EN 61010-1:2010 IEC/EN 61010-2-030:2010
Working temperature 0 °C to +40 °C
Storage temperature -10 °C to +50 °C
Working humidity 10 % to 85% relative humidity w/o condensation
Fuse Rating Ceramic 10 A/250 V (5 mm x 20 mm)
Product manufactured in China
18. Maintenance
Do not open the adapter case. It contains no user-serviceable parts. Repair or servicing should be
performed only by qualified personnel.
