AVTMMTO3xx Rev 3 Sept 2013
60
CODE Error Description Possible Cause
222 Too much voltage ripple for the 25 volt
reference
223 Too much voltage ripple for the VICOR
power supply at 5 volts
224 Too much voltage ripple for the VICOR
power supply at 20 volts
225 Too much voltage ripple for the VICOR
power supply at 40 volts
226 UNDER status input failed
227 OVER status input failed
228 EEPROM byte writing error
229 EEPROM byte reading error
230 EEPROM is uninitialized
231 Discharge temperature too much ripple
232 5V5 voltage out of range
233 5V5 voltage too much ripple
234 VICOR power supply failed at 5v, voltage
too high
235 VICOR power supply failed at 5v, voltage
too low
236 VICOR power supply failed at 20v, voltage
too high
237 VICOR power supply failed at 20v, voltage
too low
238 VICOR power supply failed at 40v, voltage
too high
239 VICOR power supply failed at 40v, voltage
too low
240 VICOR power supply failed at loop test,
