Megger OTS PB Series Quick Start Guide

www.megger.com 9
OTS PB and OTS AF Range
Fully automatic insulating oil dielectric breakdown testing
ORDERING INFORMATION
Description Order Code
OTF PB Models
OTS60PB
OTS60PB-EU 1014-525
OTS60PB-UK 1014-526
OTS60PB-US 1014-527
OTS60PB-AU 1014-528
OTS80PB
OTS80PB-EU 1014-529
OTS80PB-UK 1014-530
OTS80PB-US 1014-531
OTS80PB-AU 1014-532
Included accessories (OTS PB models)
Vessel 400 ml assembly (stirrer lid fitted)
Full electrode set - IEC and ASTM
IEC and ASTM impeller
Printer,
NiMH battery,
Electrode gauge set
Calibration certificate
Power DB guide
Quick Start Guide
OTS Vessel Preparation Guide
OTF AF Models
OTS60AF
OTS60AF-EU 1014-533
OTS60AF-UK 1014-534
OTS60AF-US 1014-535
OTS60AF-AU 1014-536
OTS80AF
OTS80AF-EU 1014-537
OTS80AF-UK 1014-538
OTS80AF-US 1014-539
OTS80AF-AU 1014-540
OTS100AF
OTS100AF-EU 1014-541
OTS100AF-UK 1014-542
OTS100AF-US 1014-543
OTS100AF-AU 1014-544
Included accessories (OTS AF models)
Vessel 400 ml assembly (stirrer lid fitted)
Printer
Full electrode set - IEC and ASTM
Electrode gauge set
IEC and ASTM impeller
Calibration certificate
Power DB guide
Quick Start Guide
OTS Vessel Preparation Guide
If you wish to upgrade your existing OTS please contact your local
Megger Authorised Service Center for prices and availability
Description Order Code
Optional accessories
OTS IEC60156 Electrode set contents - supplied in accessory
case
12.7 mm spherical electrodes (2)
36 mm mushroom electrodes (2)
Magnetic stirrer bar (2)
Magnetic stirrer bar retriever (1)
Gap gauge set 1001-477
OTS ASTM D877/D1816 Electrode set contents – supplied in
accessory case
25.4 mm standard (sharp edges) cylindrical electrodes (2)
25.4 mm non-standard (round edges) cylindrical electrodes (2)
36 mm mushroom electrodes (2)
Magnetic stirrer bar (2)
Magnetic stirrer bar retriever (1)
Gap gauge set 1001-478
Full electrode set (covers IEC and ASTM standards)
12.7 mm spherical electrodes (2)
36 mm mushroom electrodes (2)
25.4 mm standard (sharp edges) cylindrical electrodes (2)
25.4 mm non-standard (round edges) cylindrical electrodes (2)
Magnetic stirrer bar (2)
Magnetic stirrer bar retriever (1)
Gap gauge set 1001-479
Vessel lid mounted impeller (ASTM or IEC)
for use with 400 ml vessel 1001-102
Carry bag (padded) OTS80PB 1001-476
Carry bag (padded) OTS60PB 1001-480
Vessel 400 ml assembly (no electrodes supplied) 1001-473
Vessel 150 ml assembly (no electrodes supplied) 1001-474
VCM100D digital voltage checker 1001-105
VCM80D digital voltage checker 1001-801
Printer paper, 20 rolls
(4 rolls supplied if printer configured) 1008-030
Printer Ribbon Cassette 25995-002
Barcode reader, USB 1001-047
Transport case (with wheels) 1001-475
ASTM alternative propeller shaft assy 1007-153
IEC alternative propeller shaft assy 1007-154
Electrodes - Spherical (pair) 6220-484
Electrodes - Mushroom (pair) 6220-580
Electrodes - Cylindrical (pair) 6220-483
Electrodes - Non-standard cylindrical with
0,5 mm edge radius (pair) 6220-538
Electrode gauge set 1, 2, 2.5, 2.54, 4 mm 1002-144
European
Schuko CEE7/7
UK
BS 1363
US
NEMA WD6 15-5P
Australian/New Zealand
AS/NZS 3112
EU Lead UK Lead US Lead AU Lead
