Meguiar’s G110 - Parts Description; Parts List

NO. DESCRIPTION
1 BACKING PLATE
2 SPINDLE
3 SCREW
4WASHER
5 COUNTERWEIGHT
6CLIP
7 BEARING6001
8WASHER
9 SCREW
10 WASHER
11 ECCENTRIC WASHER
12 ECCENTRIC HOUSING
13 COVER
14 BEARING WASHER
15 BEARING R6
16 SPACER
17 SPACER
18 SCREW
19 GEAR HOUSING
20 GEAR SHAFT
21 GEAR
22 PLATE GEAR
23 GEAR HSG.COVER
24 SCREW
25 D HANDL
E
NO. DESCRIPTION
26 PINION
27 O RING
28 BEARING 627
29 ROTOR
30 SCREW
31 BRUSH HOLDER
32 BRUSH SPRING
33 CARBON BRUSH
34 BAFFLE
35 SCREW
36 BEARING MOUNT
37 STATOR
38 V.S DIAL
39 SWITCH
40 WASHER
41 SWITCH COVER
42 SWITCH SLIDE
43 MOTOR HSG.
44 ON/OFF BUTTON
45 POWER CORD
46 SCREW
47 CORD SLEEVE
48 MOTOR HSG. CAP
49 SCREW
50 CORD CLIP
10
PARTS DESCRIPTION
Refer to corresponding #’s in Fig. 8 on opposite page.
