Page 9 of 10

Selecting Predefined Cassette

The CF7000 has stored in memory a selection of predefined tube cassettes that

provide different payout options. (See table below).

By pressing the correct button code on the keypad you can select the required

payout option.

The correct button sequence code can also be found on the front label of the

cassette.

To select a predefined cassette, press the ‘Mode’ button then ‘D’ followed by the

button code.

Finally select ‘Accept’ from the menu to confirm and save.

Button

Code

Tube A Tube B Tube C Tube D Tube E

AA 5c 10c 50c 20c 5c

AB 1c 10c 50c 2c 5c

AC 5c 10c 50c 20c 1

AD 5c 10c 50c 10c 1

AE 5c 10c 50c 10c 5c

BA 10c 10c 50c 10c 1

BB 10c 10c 50c 20c 1

BC 20c 10c 50c 1 2

BD 1 - 50c 1 2

BE 1 - 50c 2 2

CA 1c 10c 50c 1 5c

CB 20c 10c 50c 1 20c
