(G.1) Removal of Entire Bracket and Mirror
1) Remove antenna from top of mirror.
2) Ensure that the mirror has support and remove the four
screws from the lower bracket holder. DO NOT allow mirror
system to fall away from truck.
3) Remove two screws from upper bracket holder. Entire
bracket is now free from truck.
4) Disconnect antenna and remote/heating wire harness (if
installed) from plugs in door.
To re-install bracket:
1. Plug antenna and control cables back in to the door.
2. Use the two screws to attach upper holder to truck.
3. Reattach lower bracket with four screws.
