Memorex MT1091 - LOCATION OF CONTROLS; Front Panel Controls; Rear Panel Connections; Remote Control Sensor

– 3 –
LOCATION OF CONTROLS
IN
VIDEO
EXT.ANT.
UHF/VHF
AUDIO
DC−12V
MultiFunctionRemote
OnScreenDisplay
VOLUME CHANNEL
POWER
R
7 6 5432 1 @!098
7 EARPHONE JACK ( )
8 ANTENNA HOLDER
9 AUDIO IN (put) JACK
10 VIDEO IN (put) JACK
11 DC INPUT JACK
12 VHF/UHF EXT. ANT. JACK
1 POWER SWITCH
2 CHANNEL ▲(UP) BUTTON
3 CHANNEL ▼(DOWN) BUTTON
4 VOLUME ▲(UP) BUTTON
5 VOLUME ▼(DOWN) BUTTON
6 REMOTE CONTROL SENSOR
