Men'sHealth Active+ 455 / 2248 - Complete Part List

Part #
Descriptions
Qty
Part #
Descriptions
Qty
1
Right Slant Upper Frame
1
39
Ø97 Pulley
14
2
Left Slant Upper Frame
1
40
Pulley Level Bracket
8
3
Right Slant Base Frame
1
41
Level Bracket Bush
8
4
Left Slant Base Frame
1
42
□60×50 Sleeve
4
5
Weight Stack Cover Support
2
43
Ø16 End Cap
2
6
Upper Bar
1
44
Nylon Bush
4
7
Main Base Frame
1
45
Foot Cover
4
8
Upper Frame
1
46
Sleeve
4
9
Rear Stabilizer
1
47
Rubber Bumper
4
10
Guide Rod
2
48
Ø37×465 Handle Grip
2
11
Right Upright Support
1
49
Ø31×255 Handle Grip
2
12
Left Upright Support
1
50
2" Spring Collar
2
13
Lat Bar
1
51
2" Spring Collar Cap
4
14
Swivel Pulley Bracket
2
52
U-Shaped Connector
1
15
Foot Plate
1
53
Pin
2
16
Load Support
1
54
Bush
4
17
Connecting Rod
1
55
Ø25×135 Handle Grip
2
18
Right Sliding Adjustment Frame
1
56
Ø25×325 Handle Grip
2
19
Left Sliding Adjustment Frame
1
57
Single Strap
2
20
Weight Plate Post
2
58
Ø22×15 Pulley Bushing
4
21
Weight Stack Cover
1
59
Tricep Rope
1
22
Double Floating Pulley Bracket
4
60
M10×16mm Allen Bolt
12
23
Saddle-Shaped Strap
1
61
M10×25mm Allen Bolt
9
24
Pull Bar
1
62
M10×35mm Allen Bolt
1
25
200×55 Bracket
3
63
M10×40mm Allen Bolt
7
26
150×55 Bracket
1
64
M10×45mm Allen Bolt
8
27
120×50 Bracket
2
65
M10×50mm Allen Bolt
4
28
120×45 Bracket
1
66
M10×65mm Allen Bolt
2
29
60×1.5 End Cap
7
67
M10×85mm Allen Bolt
2
30
60×2.0 End Cap
2
68
M10×80mm Carriage Bolt
20
31
30×60 End Cap
4
69
Ø10mm Washer
88
32
Ø32×2.0 End Cap
4
70
M10 Aircraft Nut
47
33
Ø25×1.5 End Cap
2
71
15 Link Chain
3
34
Ø25×2.0 End Cap
4
72
7# Carabiner
5
35
1" Spring Collar Cap
4
73
Upper Cable
1
36
Ø19×2.0 End Cap
2
74
Right Lower Cable
1
37
Lock Knob
2
75
Left Lower Cable
1
38
Ø78 Pulley
7
76
1" Spring Collar
2
Part List
27
