Men'sHealth Active+ 455 / 2248 - Assembly Instructions; Step 1: Base Assembly

:
Two person assembly recommended
Assembly Instructions
a. Attach the Guide Rods (10) to the Rear Stabilizer (9) using 2×M10×25mm Allen Bolts (61) and
2×Ø10mm Washers (69).
b. Attach the Weight Plate Post (20) to the Rear Stabilizer (9) using 2 × M10×25mm Allen Bolt (61) and
2×Ø10mm Washers (69).
c. Put 4 x Rubber Rumpers (47) on the Guide Rods (10) and Weight Plate Posts (20).
Notes: parts (30), (34), (45) are pre-assembled.
Step 1
9
