Menvier Security SD1+ - Call Routing and Control; Call Routing

6. Control Panel Connections
The table below shows the connection details to various control panels.
Control Panel TRIG A
Fire
TRIG B
PA
TRIG C
Alarm
Polarity Supply + Supply - Trigger
Type
Menvier TS400/TS410 Zone 4 Zone 5 ALM - Aux + Aux - 0V app.
Menvier TS510 N/A OP 2 * OP 1 * + Aux + Aux - 12V app.
Menvier TS690R OP 1 OP 2 OP 3 - Aux + Aux - 0V app.
Menvier TS690/TS700 Digi 1 Digi 2 Digi 3 - Aux + Aux - 0V app.
Menvier TS790/TS900/TS2500 Digi 1 Digi 2 Digi 3 - Aux+ Aux - 0V app.
A1 Advantage N/A N/A Bell - - Aux + Aux - 0V app.
ADE Optima XM N/A N/A B - 13V + 13V - 0V app.
ADE Optima 2+ Fire PA Intruder - 13V + 13V - 0V app.
ADE Concept 6 N/A N/A B - 13V + 13V - 0V app.
ADE Accenta 6 N/A N/A B - 13V + 13V - 0V app.
Ademco Infra 6 N/A N/A 3 + Aux + Aux - 12V app.
Ademco Infra 16 1* 2 3 + Aux + Aux - 12V app.
C & K 700L N/A N/A S- - Aux + Aux - 0V app.
CQR Premia 9 FA * PA IA + Aux 12V Aux 0V 12V app.
DA Abacus 6 N/A N/A Bell - +12V 0V 0V app.
DA Abacus 8 N/A N/A Bell - +12V 0V 0V app.
Gardtec 500 Series N/A N/A Bell - - Power + Power - 0V app.
Gardtec 800 Series D1 * PA 12Hr - 12V 0V 0V app.
JSB Regent COM1 COM2 COM3 + 12V 0V 12V app.
Pyronix Paragon + /E N/A N/A BA - Aux + Aux - 0V app.
Pyronix Octagon N/A PA ALM - Aux + Aux - 0V app.
Pyronix Conqueror N/A N/A BA - Aux + Aux - 0V app.
Scantronic 9448 N/A COM 2 COM 3 - 12V 0V 5V rem.
Scantronic 9452/3 N/A COM 1 COM 3 - Aux 12V Aux 0V 5V rem.
Scantronic 9454 N/A COM 1 COM 3 - 12V 0V 5V rem.
Scantronic 9455 N/A COM 1 COM 3 - 12V 0V 5V rem.
Texecom Veritas R8 N/A N/A B - Aux + Aux - 0V app.
Texecom Veritas 8 Compact N/A N/A B - Aux + Aux - 0V app.
* Control panel output requires programming.
+
When using the bell output to trigger the SD1+, you may find that the external sounder is
partially triggered. If this is the case a 1K resistor will need to be connected between the
SD1+ trigger input and +12V.
