125 pcs.
514.300.20.0115
PU
Ref. No.
125 pcs.
924.200.40.0215
PU
Ref. No.
Soft-close® CS Set
125 set
924.200.40.0115
PU
Ref. No.
Soft-close® CS Adapter
With pre-mounted Soft-close®
1 Set concisting of:
1 Soft-close® CST adapter with
pre-mounted Soft-close®
1 Hinge cup cover cap CS
2 Hinge arm cover caps
Cover cap for CS hinge cup
steel, nickel plated
125 pcs.
514.300.21.0115
PU
Ref. No.
nickel plated, unprinted
1000 pcs.
514.300.21.0215
PU
nickel plated, unprinted
1000 pcs.
514.300.22.0015
PU
Ref. No.
nickel plated, unprinted
For hinge cranking 00 For hinge cranking 08 and 15
Cover caps
PU = Packing unit
CS Click-on Scharnier-Übersicht
Page 1.2.4
For hinges CS04, CS 05, CS 22 and CS 29
Soft-close
®
CS
1.5.10
