Soft-close® CS – quick and easy to install.
Mounting is toolless, easy and quick:
1Take door off the cabinet, place it horizontal on a stable surface. Remove cover cap
(if installed) on 00 cranking hinges.
2 Insert Soft-close® CS adapter into notches located on the sides of the hinge cup and attach
adapter.
3Press both sides of the adapter downwards until you hear a noticeable “click”.
4 Mount cover cap on hinge if desired (cover cap is included in set).
5 Adjust Soft-close® CS to different opening angles and cranking if necessary via adjustment
screw.
6 Use cover for hinge cup (included in set) for the hinge without Soft-close® CS to achieve a
uniform appearance.
4
1 2
5
3
6
Please check:
Are notches located on both sides of the
hinge cup?
Soft-close®
1.5.9
