07
ASSEMBLY INSTRUCTIONS
7.Complete assembly of #7 Front Stabilizer.
8.Prepare #8 Rear Stabilizer, two #9 Screws
and A: Allen Key.
9.Align the holes on #8 Rear Stabilizer and
the rear bracket on the #1 Main Frame.
10.Insert two #9 Screws into the holes.
11.Tighten and secure the two #9 Screws
with A: Allen Key.
12.Complete the assembly of #8 Rear
Stabilizer.
To Next Page
