PART LIST MF285671
1 Post
1PC 1PC
11 Vertical ladder bar
2PCS
4PCS
1PC
2 Post
4 End guard rail
12 Horizotal ladder bar
9 Slats
8 Side rail
HARDWARE LIST MF285671
A Bolts
E End cap
4*59
1PC
F End cap
K Allenkey
1/4"*15
20PCS
1/4"*35
8PCS
1/4"*45
24PCS
30*30
8PCS
1/4"*40
4PCS
B Bolts C Bolts
D Bolts
25*25
2PCS
G End cap
20*20
4PCS
H End cap
1/4*40
2 SET
I
Connect wall
40*20
2PCS
Hollow
7 Guard rail
1PC
3 Post
5 End guard rail
2PCS
2PCS
10 Slats
Screw hole
38PCS
2PCS
14 Post
13 Slide guard
6 Guard rail
1PC
2PCS
PAGE 3 OF 8
TWIN OVER TWIN BUNK BED
ASSEMBLY INSTRUCTIONS
SKU : MF285671
3PCS 2PCS
